Titanium Niobate
TiNb2O7
- Catalog Number
- TI-5435
- CAS Number
- 12396-78-0
- Formula Mass
- 345.67 g/mol
- Physical Form
- White powder
Product Description
Titanium niobate is a monoclinic oxide containing titanium and niobium. Its crystal structure accommodates reversible lithium insertion, making it of interest for battery anode development and energy storage research. Material performance depends on particle characteristics, composition, electrode formulation and processing.
- Market Focus: Lithium Ion Batteries
- Categories: Oxides
- Synonyms: Titanium niobium oxide, niobium titanium oxide, titanium niobate, TNO, NTO
Additional Properties & Information
| Appearance | White powder |
|---|---|
| Density | 4.33 g/cm³ |
| Formula Mass | 345.67 g/mol |
| Crystal System | Monoclinic |
Product Specifications
| Formula Mass | 345.67 g/mol |
|---|---|
| Density | 4.33 g/cm³ |
| Crystal System | Monoclinic |
| Refractive Index | Approximately 2.37 at 589 nm, reported as an average measured on polished specimens |
Identifiers
| Formula | TiNb2O7 |
|---|---|
| CAS Number | 12396-78-0 |
| IUPAC Name | Diniobium titanium heptaoxide |
| InChI | InChI=1S/2Nb.7O.Ti/q2*+5;7*-2;+4 |
| InChI Key | NWZJNTOSXLNHAH-UHFFFAOYSA-N |
| SMILES | [Nb+5].[Nb+5].[O-2].[O-2].[O-2].[O-2].[O-2].[O-2].[O-2].[Ti+4] |
Safety Information
Applications
Lithium ion battery anode materials, energy storage research, electrode formulation and development.
