Zinc Sulfide
- Formula: ZnS
- |
- CAS No: 1314-98-3
- |
- EC No: 215-251-3
Zinc Sulfide is available as 99.99 pure (metals basis) 1-2 micron powder, CVD grade granules or tablets, or as a nano-powder. Zinc Sulfide is available in large batch quantities for potential uses as a phosphor host, in optical coatings, or as an infrared window material. Lorad has developed a novel proprietary method for sintering Zinc Sulfide to high density.
Other Identifiers
- Catalog #ZI-5940
Zinc Sulfide Notes
ZnS powder at 1-2 microns is the source material for our tablets and granules for the vacuum evaporation of thin film coatings.
It should be noted that we also manufacture a range of very high purity zinc dialky dithiocarbamates, specially purified to be suitable for the chemical vapor deposition of zinc sulfide thin films. Lorad can provide user information to customers relating to the conditions for thin film growth, and the application of these precursors in an aerosol and conventional CVD source application.
- Zinc diethyldithiocarbamate
- Zinc ethylxanthate
Get a Quote on Zinc Sulfide
Zinc Sulfide Physical Properties
- Molecular Weight97.47 g/mol
- Typical Purity99.99
- Form
Zinc Sulfide powder is available in bulk as a high purity, (very low transition metals) 1-2 micron powder.
Our 1-2 micron powder can be provided in CVD grade granules or as tablets.
Zinc Sulfide is available as a nano-powder.
- Theoretical Density4.1 g/cm³
- Melting Point1,850ºC (3,362°F)
Zinc Sulfide Optical Properties
- Refractive Index2.35 at 550nm
- Transmission Range380nm - 14µm
- Evaporation Temperature1000 - 1100ºC
- Evaporation Sourcee-beam, Mo, Ta, Al2O3
